  • Part Number: RA019

Manufacturer: Miscellaneous

Guide Roller L Frame Assembly (1 Roller 100x30)

£220.00
file icon Download Datasheet

Dimensions:

Bracket - 200mm Long x 75mm Wide x 150mm Deep
Guide Roller - 100mm OD x 30mm Wide (93° shore A) and L Shaped Guide Liner - 140mm Long x 25.5mm Wide

Comments: Suits 16mm Guide Rail
Not Handed - Roller & Guide Shoe can Easily be Swapped to the Opposite Side on Site.

ACLA 140mm Long Half Aluminium Guide Shoe PartNo. 10112

ACLA Polyethylene Guide Shoe Liner to Suit 16mm Rail Part No. 10184

Standard Next Working Day Delivery (Mainland UK) - £15

Free Delivery on orders over £100

Please see our Delivery & Returns page for more options
